Four Column Hydraulic Machine Model Y32 With Stamping, Bending, Turning-Up And Extending

Four Column Hydraulic Machine Model Y32 With Stamping, Bending, Turning-Up And Extending
Four Column Hydraulic Machine Model Y32 With Stamping, Bending, Turning-Up And Extending Four Column Hydraulic Machine Model Y32 With Stamping, Bending, Turning-Up And Extending

Large Image :  Four Column Hydraulic Machine Model Y32 With Stamping, Bending, Turning-Up And Extending Get Best Price

Product Details:
Place of Origin: China
Brand Name: FAST
Certification: ISO9001
Model Number: Y32
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 10000~15000
Packaging Details: plywood pallets
Delivery Time: 30days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300sets/year
Detailed Product Description
Condition: New Warranty: 12 Months
Port: Qingdao Port MOQ: 1 SET
Service: 24 Hours Online Services Voltage: 380V
Certificate: ISO9001 CNC Or: CNC
Manufacture: OEM ODM Acceptable Funtion: Stamping, Bending, Turning-up And Extending

Four Column Hydraulic Machine Model Y32

Four Column Hydraulic Machine Model Y32 With Stamping, Bending, Turning-Up And Extending 0



APPLICATION

The machine is suitable for processing shapeable materials, such as stamping, bending, turning-up and extending functions. This machine can be also used for straightening, pressing, plastics mold compacting, ect.



ADVANTAGES

● Independent dynamic mechanism and electric system.

● PLC controlling system.

● Adjustable/ manual/ semi-auto/ automatic operations.

● Multi-machine movement synchronous running.



TECHNICAL DATA

Model Y32-40 Y32-63 Y32-100 Y32-160 Y32-200 Y32-315 Y32-500
Nominal Force (kN) 400 630 1000 1600 2000 3150 5000
Ejection Force (kN) 63 100 250 250 400 630 1000
Max. Working Pressure (Mpa) 25
Stroke of Slider (mm) 400 450 500 560 700 800 900
Max. Opening Height (mm) 600 700 800 900 1120 1250 1500
Working Table Size (mm) 400*400 500*500 630*630 800*800 900*900 1200*1200 1400*1400
Slider Speed (mm/s) Moving down 40 60 80 100
Working 10 15 8
Returning 60 80 100
Outline Dimension (mm) 1320*1480*2400 1380*1900*2530 1450*2500*3200 1600*2670*3350 1900*2780*3900 2120*3100*4800 2400*4100*5300
Motor Power 5.5 7.5 11 11 15 22 37
Total Weight 2 2.7 4.5 6.5 12 16 32

★ All of these models can be customized according to customer requirements.
